Product Description

Carling AV Push Button Switch

Latching, ON-OFF, Carling P/N: AV1-1B211E-R00

Momentary, (ON)-OFF, Carling P/N: AV1-1A211E-R00

The Carling AV Push Button Switch is a great little switch — very affordable, and it has an impressive 10A current rating (2x that of its leading competitor!)

Available in latching ON-OFF or momentary (ON)-OFF – select which using the drop-down menu.

Most common recreational boating loads can run directly off this 10A rated switch.

It has both a normally closed and normally open contact, which allows you to use the switch to break a normally closed circuit if desired.

Plus, it features an independent blue LED ring.  This can be linked to the switch output with an external jumper to make the light come on when the switch is on.

More about Carling AV Push Button Switches:

Carling part numbers AV1-1B211E-R00 and AV1-1A211E-R00 are both on this listing, select which you need using the drop-down menu.

The AV-Series Push Buttons by Carling Technologies is a sealed, potted switch featuring a modern, stainless steel design.

AV-Series Top Features:

• Dry Contact
• Ultra-low profile that stands out only 2.01 MM (0.079 IN) from a panel
• Sealed to IP67 for above-panel components
• Independent Blue LED halo illumination
• UL1500 ignition protection
• Easy to install

This push button series features 0.110 quick-connect tab terminals (14-16 AWG and 18-22 AWG) for easy installation and daisy-chaining — and that means less time wiring and more time out on the water.

Technical Specs:

The Carling AV series sports a generous 10A rating even with a dry contact (non-solid state) version. This is a true innovation, allowing most loads to be switched directly without a transistor!

• 10A current rating
• LED rating 12 VAC/DC @ 15mA
• Momentary or maintained
• Actuator: Stainless Steel 316

This is a genuine Carling Technologies push button — not some cheap knockoff like you might find other places online.

Carling AV-Series Push buttons can accommodate panels up to 1/4″ thick — this is a shallower threaded body than some of the other push button options. If you purchase a thicker panel from New Wire Marine, we will mill it down to accept the switches.

These switches are NOT resettable – meaning you’ll need to protect them with a fuse or circuit breaker like any other switch: They do not have it built in.

Download the full spec sheet here.

Why go with a Carling AV Push Button Switch?

It all depends on your desired aesthetic. Designed to be flush with your panel, push buttons stand less proud from the surface compared to rocker switches and toggle switches — and the result is a clean, modern-looking dash. This switch from Carling is an affordable option that still allows a whopping 10A.

Interested in a fully custom panel?

As with any of our components, we’d be happy to pre-assemble Carling push buttons into a complete, fully custom panel unit for you — that way you can get OEM-quality switch labeling correctly applied to the dash. Get a quote here.
