Marine Circuit Protection

Proper marine circuit protection is a critical part of your boat’s electrical system. Quickly and safely opening a circuit experiencing an overcurrent event can prevent catastrophic electrical fires. New Wire Marine carries a variety of marine-grade circuit protection devices, all approved for maritime use.

Proper marine circuit protection is a critical part of your boat's electrical system. Quickly and safely opening a circuit experiencing an overcurrent event can prevent catastrophic electrical fires. Read More New Wire Marine carries a variety of marine-grade circuit protection devices, all approved for maritime use. Read Less

Circuit Breakers

These top-quality, marine grade thermal circuit breakers are the same type we use in our awesome custom boat dash & switch panels.

  • Options
  • Options
  • Push-to-Reset Circuit Breaker

    $5.00
    Options
  • Screw Terminal Breaker

    $5.00
    Options
  • Circuit Breaker Boot Replacement

    $2.00
    Add to cart
  • 6 Circuit Breaker Block w/ Neg Bus

    $47.00$71.00
    Options
  • Options

A & C Series Circuit Breakers

  • Options
  • Options
  • Options

Fuse Blocks and Holders

Our Marine Grade Fuse and Breaker Blocks are great for providing quality circuit protection for your boat.

  • Add to cart
  • RT 6 Circuit Fuse Block

    $22.00$28.00
    Options
  • Waterproof In-Line Fuse Holder

    $6.00
    Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • 12 Circuit Fuse Block w/ Neg Bus

    $54.00
    Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Options
  • Options
  • Add to cart
  • Add to cart
  • MIDI/AMI Single Fuse Block

    $28.00
    Add to cart
  • Add to cart

ATC Fuses

Probably the most common fuse ever, we carry a variety of fuse blocks that accept ATC fuses, like this one: 12 Circuit Marine Fuse Block.

  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart

Maxi Fuses

Maxi fuses are physically about twice the size of an ATC fuse, and go in a maxi fuse holder like this one.

  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart

AMI Fuses

AMI fuses come in higher current ratings.  We carry a single AMI fuse holder, and four of them can be mounted in our SatefyHub Fuse Block.

  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart

Mega Fuses

Mega fuses are used for extremely high current circuit protection.  We carry only a single Mega fuse holder.

  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart
  • Add to cart

All about

Why is Circuit Protection Necessary?

Your entire boat’s electrical system is driven by a very powerful source: A battery. Intentionally – and necessarily – this battery can push a huge amount of electrical current (amps) if it is allowed to do so. This allows the battery to do beneficial work, like cranking your engine and pumping lots of water out of your bilge. But it also creates some risks:

Your marine battery – if given the chance – will try and push as much current from positive to negative as it can… hundreds or thousands of amps. Smaller wire meant for much smaller loads it not designed to handle nearly that much current. Typically somewhere around 10x the rated current of that wire – without proper protection – it will heat up so hot it will begin melting the insulation off the wire.

A direct short circuit event is where a positive and negative wire become tied directly together, and a strongly tied direct short is generally the worse case scenario.

Too much current – just like the burners in your oven – can cause enough heat to start a fire. And the smaller the wire gets – the more heat is generated from the same amount of current.

The last thing you want to happen is to run the risk of an on-board fire while you are out on the waters!

How does Proper Marine Circuit Protection Prevent This?

Overcurrent circuit protection is really pretty simple. These devices are made to sense the amount of current and open the circuit when the exceeds the capacity of the wires. Opening a circuit makes a break – an air gap of very high resistance – which stops all current from flowing through that wire.

What are the Main Types of Circuit Protection on Boats?

There are two main categories of overcurrent protection on boats:

  1. Circuit Breaker
  2. Fuse

In general, breakers and fuses accomplish the same purpose, and can be used interchangeably.

Circuit Breakers

Circuit breakers are electro-mechanical devices specifically designed to protect electrical circuits from overload of current or short circuit. It interrupts the current flow the moment a fault in the flow is detected. It is automatically tripped by the surge of current. Once they have been tripped, they need to be manually reset. The primary benefit of breakers are that they don’t need to be replaced after being tripped. They are re-usable.

Fuses

A fuse contains a conductor that is designed to destructively fail when it reaches a set amount of current through it. When a fuse blows the element is permanently destroyed, so it needs to be replaced. The main benefit of fuses is they are generally less expensive than breakers.

Tell me a Little About Proper Circuit Protection Design?

Circuits – Like a Tree

Imagine your boat’s electrical system like a tree, where the battery is at the base. The main trunk is a larger conductor (wire), and like a tree trunk carries all the nutrients from the soil to all the branches – the main battery feed also carries all the current.

So if the main feed carries all the combined current (amps) of all the loads on the boat, then it needs to be a larger conductor with a larger circuit protection device.

Less and Less Current as you go

Each time a branch comes off the three it now only carries the nutrients (current) of the loads that are downstream of where that branch splits from the main line. Then each limb, twig and leaf can use smaller and smaller wire, and have smaller and smaller circuit protection devices.

Prevent Larger System Loss

With a properly designed system, each circuit protection device, sequentially placed downstream will always be smaller than the previous. This is important because you want only the smallest circuit protector to trip or blow. Otherwise you’re at risk of losing more branch circuits.

For example: if you used all 10A fuses for your branch feeds and main feed, several downstream loads coming on at the same time might blow your main fuse. This will result in every load being shut off, even though none of the devices were experiencing an overcurrent event.

marine circuit protection wiring diagram

In the example above, you can see how each progressive circuit protection device gets smaller and smaller as they go downstream away from the battery. They are protecting a smaller load, using smaller gauge wire… so this make sense.

The ABYC says that a circuit protection device should be sized no greater than 150% of the rated current of the conductor that it feeds. And no greater than the sum of all next-in-line protection devices.

A main feeder breaker that is smaller than all next-in-line downstream fuses or breakers is fine. Because in practice, you should never experience maximum load on all circuits at the same time… it is just not realistic, as there are duty cycles applied to nearly every load.

Anything else that People Find Confusing?

Yes… a few things:

Finding Exactly Sized Circuit Protection

We often get the comment “I can’t use a 5A breaker because the specs on my light says it only draws 2.2A”

Not true: It is a common practice to round up to the nearest available breaker/fuse size than your loads draws. In fact, as long as you don’t exceed 150% of the capacity of the smallest conductor feeding the load, it would still be considered properly designed.

The reality is that in a boat, branch circuit protection is really there to prevent a catastrophic event in the wiring… usually not to protect the actual device from damage. After-all, if the short circuit happens on one of the PCBs (Printed Circuit Boards) in your underwater lights, the light is going to be fried long before the 5A fuse blows.

If super specific – device saving – circuit protection is truly required for an expensive device, the manufacturer should provide that internal to the component as a specifically designed and specified internal fuse – and not put it on the customer to find some random 2.25A fast-blow fuse.

So in most cases, it is a common practice to round up the circuit protection device from the load’s actual current draw. Spurious – unwanted – tripping is a larger concern (inconvenience) than protecting the circuit a few amps higher than the load’s specified current draw.

My Circuit is Drawing 6A and my 5A Breaker is not Tripping

Correct, and nor should it. Circuit breakers and fuses are designed with trip delays built in based on the percent of the rated capacity of the breaker or fuse.

They are made to allow temporary startup surges and transient events to not cause unwanted tripping. As discussed above – they are made to protect from a catastrophic event – and in that case, will open immediately. But a current that exceeds the rated capacity by a small amount may take many minutes before it trips the device.

There are many factors involved in the design of breakers and fuses, but just as an example here’s what a typical circuit breaker trip speed curve looks like:
