Bilge

$5.99

(13 customer reviews)

Bilge Rocker Switch Cover

Genuine Carling Contura II covers.

Both Red and Blue Lens Available.

SKU: act-11 Category:

Product Description

Bilge Switch Cover


Genuine Carling Contura II rocker switch cover labeled “Bilge”.  All our covers (called “actuators”) are precision printed with UV stabilized ink.  We only print onto the hard style plastic actuators, not the “soft touch” that melts in the sun and becomes a sticky mess.

This product is the COVER ONLY.  Find an entire replacement Bilge Rocker Switch here.

This Bilge switch cover will fit on any Carling V-series or contura style switch body or base.  That includes contura style bases sold by Carling, Sierra, Blue Sea Systems, Sea-Dog… or a myriad of other brands.

Actuators are SUPER easy to change out.  Your old covers can be removed easily from the switch body from the front of the panel using this actuator removal tool.  Your new Bilge switch cover will pop right back on.  All service done from the front of the panel with NO need to remove the switch (literally a 5 second job here).

How to Determine if it will fit your switches:

  1. Check the “will it fit” tab on this page, if your switch looks like any of these styles, it will fit.
  2. If your switch has a 4 digit part number on the side (behind panel), starting with a “V” (ex: V1D1), it will fit.
  3. If your switch has a removable actuator and is approx: 15/16″ wide and 1 15/16″ tall, it will most likely fit.
  4. When in doubt, Contact us and send us a picture of your existing rocker switches and we’ll tell you.
  5. Have no fear!  If it does not fit it can be returned for a refund in accordance with our return policies.

Features / Beat the Competition:

  • Guarantee – if your ink wears off within 2 years, we’ll replace them for free!
  • Genuine Carling Technologies covers – no knock offs
  • Durable UV stabilized ink
  • Hard cover style.  We never use the “soft touch” style that will melt
  • Includes ISO symbol over the lens
  • Large format text for easy reading

Contura Styles, lenses and colors:

This Bilge rocker cover is a contura II style, as pictured above.  Contura II is the one with the small bumps on it.  We carry printed contura II’s in red and blue lens options (selection from menu above).  This Bilge rocker cover will have one lens at the top, and is meant to go onto a switch that is illuminated at the top only.

We also carry this label in contura V style here.  Contura V style can be placed onto a two lamp switch, which allows a great backlighting effect for night readability.

Typical use for a Bilge Rocker Cover:



These covers are SUPER popular on boats… so if you’ve reached this page 97% chance that yes… it will fit.

Our Contura II and V switch covers are interchangeable on all Carling V-series switches.  There are many contura styles (II, III, IV, V, VI, VII, and XIV), which all look slightly different and have a variety of lens colors and looks.  This cover will replace them all and is a great way to make your dash look new again.

Visually:

The easiest way to tell is visually.  The most common actuator styles are shown below.  If your switches look similar to this, they will fit.

Contura II III IV and V-min

Contura II’s have 8 small bumps at the top and bottom.  This is the style we print onto.  Lenses can be any variety of colors (white shown here).

Contura III’s have three horizontal lines top and bottom.  This style uses a narrow bar lens only.

Contura V style is slightly rounded… shown here surrounded by contura IV style

Contura IV style has a curved almost banana shape to it.

Markings On Switch:

You’ll have to pull the switch out or crawl under the dash to check this, but matching switches will have several markings:

  • U.S. PAT. 5105059”  one one side, and on the other:
  • Carling Technologies
  • a 4 digit part number starting with a “V” (ex: V1D1)
  • 20A 12V Mexico

If your switch has any of these markings it will fit.

Take A Photo And Ask Us

Feel free to take a photo and email to sales@newwiremarine.com and we’ll tell you if they will fit.

Try it, and return it if they do not

Remember we have a 45 day no-questions-asked return policy.  If  it does not fit, just return it for a full refund.

13 reviews for Bilge

  1. Dennis Szarowicz (verified owner)

    These cover plates with labels were easy to install.

  2. David Nelson (verified owner)

    Service outstanding, great price and fast shipping. Great product at a good price.Switch covers look awesome on my boat

  3. Bob Gilmore (verified owner)

    I received my seven Switch Covers today after I ordered them online two days ago. I also ordered the Cover Removal Tool, which I am glad I did, the tool made installation simple. The total time to install the new covers on my 2002 Blazer Bay 2220 took approximately ten minutes including cleaning the surface areas. the new Switch Covers I purchased where blue and really improve the looks of my old boat. Very good quality and easy to install.

  4. Robert Gilmore (verified owner)

    I purchased seven new Custom Switch Covers to replace the damaged ones on my 2002 Bay Boat. I also purchased the Removal Tool. Replacing there old switches with the new Switches was very easy to do with the provided tool. New Switch Covers look great.

    Very easy to purchase online with fast delivery.

  5. Trace Curd (verified owner)

    The new covers were delivered as promised and look great. I would highly recommend this product to update an older cockpit for a more modern look.

  6. Michael Detrick (verified owner)

    Exactly as advertised. Look great and at a great price.

  7. Patrick Dilling (verified owner)

    Cover fit on my Stratos boat perfectly. Works great. Shipping was very fast, received it sooner than I expected.

  8. Michael Lopez (verified owner)

    The covers were an exact match and an easy install with the removal tool. Quick delivery

  9. Patrick Sweeney (verified owner)

    Perfect replacement for deteriorated switch covers.
    Great customer service, I received the product much faster than I expected.

  10. John Brill (verified owner)

    Ordered new covers to replace ones that came with the boat and had faded over the years. Replaced all seven covers in two minutes. Very quick and easy.

  11. Erik Cilen (verified owner)

    Everything fit perfectly! Wish I knew about this sooner before I bought the OEM ones.

  12. James Lohnes (verified owner)

    Flawless!

  13. Eldon McQueen (verified owner)

    Covers fit perfectly. Arrived on time in good condition.
